Miora Metal, a leading manufacturer of high-quality metal products, offers a diverse range of round bar products designed to meet the diverse needs of various industries. These round bars are renowned for their exceptional durability, precision, and versatility, making them an essential component in numerous applications.
Miora Metal's round bar products are available in a wide selection of materials, including carbon steel, stainless steel, and alloy steel, ensuring that customers can find the perfect material to suit their specific requirements. The company's commitment to quality is evident in the consistent and precise dimensions of their round bars, which are meticulously manufactured to the tightest tolerances, ensuring a seamless fit and integration into any project.
One of the key features of Miora Metal's round bar products is their superior corrosion resistance. The company's advanced manufacturing processes and the use of high-quality raw materials result in round bars that are capable of withstanding harsh environmental conditions, making them ideal for use in industries such as construction, automotive, and marine applications.
In addition to their exceptional performance characteristics, Miora Metal's round bar products also boast impressive aesthetic qualities. The smooth, uniform surface finish and the company's attention to detail ensure that these round bars not only function flawlessly but also enhance the overall appearance of any application.
Miora Metal's commitment to customer satisfaction is further demonstrated by their extensive range of customization options. Clients can choose from a variety of sizes, lengths, and finishes to ensure that the round bars seamlessly integrate with their specific project requirements, allowing them to achieve their desired outcomes with confidence.
Overall, Miora Metal's round bar products are a testament to the company's dedication to manufacturing excellence and their unwavering commitment to providing their customers with the highest quality metal products on the market.
Specifications
| Grade | Stainless Steel Round Bar |
|---|---|
| Stainless Steel Square bar size | 4 to 100mm |
| Stainless Steel Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hot Rolled Steel Hex Bar size | 2-100mm A/F |
| Stainless Steel Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Stainless Steel Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hot Rolled Steel Flat bar size | Thickness: 2 -100mm |
| Width: | Thickness: 10 to 500mm |
| Stainless Steel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Stainless Steel Section | 3.0 to 12.0mm thickness |
| Hot Rolled Steel Round bar size | Diameter: 3-~800mm |
| Stainless Steel Billet Size | 1/2" to 495mm Diameter |
| Stainless Steel Round Bar Standard Dimensions | Diameter / Height: Stainless Steel Rod and Bar Sizes : 0.5 inches / 0.625 inches / 0.75 inches / 0.875 inches / 1.0 inches / 1.125 inches / 1.25 inches / 1.375 inches / 1.5 inches / 1.75 inches / 2.0 inches / 2.25 inches / 2.5 inches / 2.75 inches / 3.0 inches / 3.25 inches / 3.5 inches / 3.75 inches / 4.0 inches / 4.25 inches / 4.5 inches / 5.0 inches / 5.25 inches / 5.5 inches / 6.0 inches / 7.0 inches / 8.0 inches / 9.0 inches. |
| Stainless Steel Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Stainless Steel Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Hot Rolled Steel Technique | Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Stainless Steel Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Stainless Steel Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square Bar, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
Material & Grade
| Stainless Steel | ASTM / ASME SA 276, A479 TP 202, 304, 304L, 309S, 309H, 310S, 316, 316L, 316 TI, 317, 321, 347, 410, 420, 430, 431, 440A, B & C., 446 |
| Duplex Steel | 2205 (UNS No. S31803), 2507 (UNS No. S32750) |
| Super Duplex Steel | ASTM / ASME SA A582, A276, A564, ASTM A484, 484M UNS NO. S32750 / S32760 / S32950 |
| Carbon Steel | ASTM / ASME A 105, A53 GR B, A106GR B, API5L GRADE B, API 5L, GRX42 / 46 / 52 / 56 / 60 / 65 / 70, A333 GR 1/GR 3/GR 6, A/SA 672 GR 8C60/C70 etc.. |
| Alloy Steel | ASTM / ASME A 182 GR F 5, F 9, F 11, F 12, F 22, F 91. ASTM / ASME A 729 GR B 11 & B 22. |
| Nickel Alloy | ASTM / ASME SB 160 Nickel 200 (N02200), Nickel 201 (N02201), Nickel 205 (N02205) |
| Monel | ASTM / ASME SB 164 Monel 400 (N04400), Monel 500 (N05500) |
| Inconel | ASTM B408, AMS 5766, ISO 9723, ISO 9724, BS 3076NA15, BS 3075NA15, EN 10095, VdTüV 412 & 434 Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750, Incoloy 800, incoloy 825, Incoloy 925, Incoloy a-286 |
| Hastelloy | Hastelloy C22, Hastelloy C276, Hastelloy C4, Hastelloy B, Hastelloy C-2000 |
| Cupro Nickel Alloy | UNS No. C70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C10100, 10200, 10300, 10800, 12000, 12200, |
Equivalents of grade Round Bars
|
MATERIAL
|
ASTM | EQUIVALENT STANDARD | |||
| UNS | GRADE (TP) | DIN (EN) | AFNOR (NF) | JAPAN (JIS) | |
|
AUSTENTIC STAINLESS STEEL
|
S30400 | 304 | 1.4301 | Z6CN18-09 | SUS304 |
| S30403 | 304L | 1.4307 | Z2CN18-10 | SUS304L | |
| S31600 | 316 | 1.4401 | Z6CND17-11 | SUS316 | |
| S31603 | 316L | 1.4404 | Z2CND17-12 | SUS316L | |
| S31635 | 316Ti | 1.4571 | Z2CND17-12 | - | |
| S32100 | 321 | 1.4541 | Z6CNT18-10 | SUS321 | |
| S34700 | 347 | 1.455 | Z6CNNb18-10 | SUS347 | |
| S30409 | 304H | 1.4948 | Z6CN19-10 | SUS304H | |
| S31609 | 316H | 1.4919 | Z6CND17-12 | SUS316H | |
| S32109 | 321H | 1.4941 | Z10CND18-10 | SUS321H | |
| S31000 | 310 | - | - | SUS310 | |
| S31703 | 317L | 1.4438 | - | SUS317L | |
|
FERRITIC STAINLESS STEEL
|
S40500 | 405 | 1.4002 | Z6CAL13 | SUS405 |
| S41000 | 410 | 1.4006 | Z12C13 | SUS410 | |
| S43000 | 430 | 1.4016 | Z10C17 | SUS430 | |
|
DUPLEX STAINLESS STEEL
|
S32205 | 2205 | 1.4462 | Z2CND22-06 | - |
| S31803 | - | 1.4462 | Z2CND22-05 | - | |
Packing Of Round Bars
- Shrink-wrapped
- Carton boxes
- Wooden pallets
- Wooden boxes
- Wooden crates
- Boxes and Crates
We Are Expert In All Industry Works
- Petrochemical
- Oil-Gas
- Chemical
- Nuclear
- Pharmaceutical
- Offshore
- Construction
- Pulp & paper
- Food processing
